| Performance |
Powerful chipset for enhanced performance and business scalability |
| Audio Quality |
Smart Noise Filtering Technology |
| Voice Quality |
HD Voice |
| Display Size |
2.4" Color LCD |
| Display Resolution |
320 × 240 Pixels |
| Ethernet Ports |
Two 10/100M Ethernet Ports |
| SIP Accounts |
Supports 4 SIP accounts |
| Codec Support |
Opus codec support |
| Conference |
Local 5-way conferencing |
| Design |
Classic, user-friendly interface |
| Stand |
Adjustable stand with 2 angles |
| Mounting |
Wall mountable |
| Power |
PoE (Power over Ethernet) |
| Additional Features |
Comfortable and practical operation |
| Audio Features |
Handset, speaker, headset support |
| Wideband Codec |
Opus, G.722 |
| Narrowband Codec |
G.711(A/µ), G.729, G.729A, iLBC |
| DTMF |
RFC 2833, SIP INFO, Inband |
| Speakerphone |
Full-duplex hands-free speakerphone with AEC |
| Audio Processing |
VAD, CNG, AEC, PLC, AJB, AGC |
| Phone Features |
Call hold, DND, Speed dial |
| Call Functions |
Call forward, call waiting, call transfer |
| Additional Call Features |
Redial, call return, auto answer |
| Conference Support |
Local 5-way conferencing |
| Other Features |
Direct IP call, Time/Date Management |
| Phonebook |
Local phonebook up to 1000 entries |
| Directory Features |
Blacklist, XML/LDAP remote phonebook |
| Dialing |
Smart dialing |
| Phonebook Management |
Search, import/export |
| Call History |
Dialed, received, missed calls |
| Display |
2.4" 320×240 pixel color graphical LCD |
| LED Indicators |
Call and message waiting indication |
| Interface |
Intuitive UI with icons and soft keys |
| Language Support |
Multilingual interface |
| Caller ID |
Name and number display |
| Function Keys |
4 line keys, 5 navigation keys |
| Feature Keys |
Message, headset, redial, mute, speakerphone |
| Volume Control |
Volume control keys |
| Network Protocols |
SIP v1 (RFC2543), v2 (RFC3261) |
| Network Features |
NAT traversal (STUN) |
| IP Assignment |
Static / DHCP |
| Web Management |
HTTP/HTTPS web server |
| Time Sync |
SNTP |
| Security |
SRTP / SIP TLS |
| Network Support |
IPv6, VLAN, LLDP |
| Provisioning |
Auto provision via FTP/TFTP/HTTP/HTTPS |
| Management |
Browser/phone configuration |
| System Features |
TR-069, System log |
| Reset Options |
Factory reset, reboot |
| IP-PBX Features |
BLF, Anonymous call |
| Call Features |
Call park, call pickup |
| LAN Ports |
2 × RJ-45 10/100Mbps |
| Handset Port |
1 × RJ9 (4P4C) |
| Headset Port |
1 × RJ9 (4P4C) |
| Mounting |
Wall mountable |
| Power Adapter |
Optional |
| Power Input |
100-240VAC |
| Power Output |
DC 5V/1A |
| Power Consumption |
2–3W |
| Dimensions |
190 × 153 × 162 × 42 mm |
| Operating Humidity |
10% – 95% |
| Operating Temperature |
-10°C to 50°C |
| Package Contents |
DPH-130SE IP phone |
| Included Accessories |
Handset with cord |
| Cable |
Ethernet Cable (1.5m CAT5E UTP) |
| Stand |
Adjustable stand |
| Documentation |
Quick Start Guide / QIG |
